MPF5020CMMACES - NXP

Description: Power Management Specialized - PMIC Power Management IC, pre-prog, 3 step-down DC/DC, 1 LDO, QM Safety Level

Download MPF5020CMMACES Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
MPF5020CMMACES - NXP - PCB symbol
click to zoom
PCB Footprints
MPF5020CMMACES - NXP PCB footprint - Other - Other - SOT618-17(D)_2025
click to zoom
3D Models
MPF5020CMMACES - NXP - 3D model - Other - SOT618-17(D)_2025
click to zoom

MPF5020CMMACES Details

  • Manufacturer Part Number:

    MPF5020CMMACES

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    9

  • Analog IC - Other Type:

    INTEGRATED POWER MANAGEMENT UNIT

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Time@Peak Reflow Temperature-Max (s):

    40
