MXO45HST-3C-8M0000 - CTS

MXO45HST-3C-8M0000 Details

• Manufacturer Part Number:

  MXO45HST-3C-8M0000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  DIP-8/4

• Country Of Origin:

  Mainland China

• Manufacturer:

  CTS Corporation

• YTEOL:

  3

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION; BAG; BOX

• Fall Time-Max:

  10 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  8

• Operating Frequency-Nom:

  8 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Oscillator Type:

  HCMOS/TTL

• Output Load:

  10 TTL, 50 pF

• Output Low Current-Max:

  16 mA

• Package Body Material:

  METAL

• Package Equivalence Code:

  DIP4/8,.3

• Packing Method:

  TRAY

• Physical Dimension:

  13.2mm x 13.2mm x 6.45mm

• Rise Time-Max:

  10 ns

• Supply Current-Max:

  25 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  TIN SILVER COPPER OVER NICKEL
