NCP58922MNTWG - onsemi

Description: Gate Drivers SINGLE CHANNEL INTEGRATED DRIVER AND GAN POWER TRANSISTOR Power Switch/Driver 1:1 N-Channel 18A 26-TQFN (8x8)

Download NCP58922MNTWG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
NCP58922MNTWG - onsemi - PCB symbol
click to zoom
PCB Footprints
NCP58922MNTWG - onsemi PCB footprint - Other - Other - TQFN26 8x8, 0.8P CASE 518AG ISSUE B
click to zoom
3D Models
NCP58922MNTWG - onsemi - 3D model - Other - TQFN26 8x8, 0.8P CASE 518AG ISSUE B
click to zoom

NCP58922MNTWG Details

  • Manufacturer Part Number:

    NCP58922MNTWG

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    onsemi

  • YTEOL:

    7

  • Analog IC - Other Type:

    LOAD SWITCH

  • Peak Reflow Temperature (Cel):

    260

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

NCP58922MNTWG Overview

Use the download button to access the NCP58922MNTWG schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like NCP58, or try a keyword search, such as Power Management Circuits
