A 2-layer or 4-layer PCB with a solid ground plane and thermal vias is recommended. The device should be placed near a thermal pad or heat sink to dissipate heat efficiently.
Ensure proper heat sinking, use a thermal interface material, and follow the recommended PCB layout. Also, consider derating the device's power dissipation according to the temperature derating curve in the datasheet.
The maximum allowed voltage on the input pins is the supply voltage (VCC) + 0.3V. Exceeding this voltage may damage the device.
Use ESD protection devices such as TVS diodes or ESD arrays on the input lines. Follow proper PCB layout and handling procedures to prevent ESD damage during assembly and testing.
Power up the device in the following sequence: VCC, then input signals. Power down in the reverse sequence to prevent latch-up or damage.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
NIS5112D2R2G Overview
Use the download button to access the NIS5112D2R2G schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like NIS51,
or try a keyword search, such as Power Management Circuits
