NSVBC114EMXWTBG - onsemi

NSVBC114EMXWTBG Details

• Manufacturer Part Number:

  NSVBC114EMXWTBG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  onsemi

• YTEOL:

  6

• Additional Feature:

  BUILT IN BIAS RESISTANCE RATIO IS 1

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  0.1 A

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  SINGLE WITH BUILT-IN RESISTOR

• DC Current Gain-Min (hFE):

  35

• JESD-30 Code:

  S-PDSO-N3

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  0.45 W

• Reference Standard:

  AEC-Q101

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• VCEsat-Max:

  0.25 V
