NT6CL256M32AM-H1 - Nanya

NT6CL256M32AM-H1 Details

• Manufacturer Part Number:

  NT6CL256M32AM-H1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.36

• Date Of Intro:

  2018-10-19

• Manufacturer:

  Nanya Technology Corporation

• YTEOL:

  4

• Access Mode:

  MULTI BANK PAGE BURST

• Clock Frequency-Max (fCLK):

  933 MHz

• I/O Type:

  COMMON

• JESD-30 Code:

  R-PBGA-B178

• JESD-609 Code:

  e1

• Length:

  11.5 mm

• Memory Density:

  8589934592 bit

• Memory IC Type:

  DDR3L DRAM

• Memory Width:

  32

• Number of Functions:

  1

• Number of Ports:

  1

• Number of Terminals:

  178

• Number of Words:

  268435456 words

• Number of Words Code:

  256000000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -30 °C

• Organization:

  256MX32

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA178,13X17,32/25

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Seated Height-Max:

  0.83 mm

• Self Refresh:

  YES

• Sequential Burst Length:

  8

• Supply Voltage-Max (Vsup):

  1.3 V

• Supply Voltage-Min (Vsup):

  1.14 V

• Supply Voltage-Nom (Vsup):

  1.2 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  BOTTOM

• Width:

  10.5 mm
