NX5P2924BUKZ - NXP

Description: IC PWR SWITCH N-CHAN 1:1 6WLCSP

Download NX5P2924BUKZ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NX5P2924BUKZ - NXP PCB footprint - BGA - BGA - WLCSP WAFER LEVEL CHIP SCALIE PACKAGE 6 BUMPS 0.87X1.37X0.50MM
click to zoom
3D Models
NX5P2924BUKZ - NXP  - 3D model - BGA - WLCSP WAFER LEVEL CHIP SCALIE PACKAGE 6 BUMPS 0.87X1.37X0.50MM
click to zoom

NX5P2924BUKZ Details

  • Manufacturer Part Number:

    NX5P2924BUKZ

  • Brand Name:

    NXP Semiconductor

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    WLCSP-6

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    0

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    LOAD SWITCH

  • JESD-30 Code:

    R-XBGA-B6

  • Length:

    1.37 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VFBGA

  • Package Equivalence Code:

    BGA6,2X3,20

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Seated Height-Max:

    0.5 mm

  • Supply Current-Max (Isup):

    0.105 mA

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    0.8 V

  • Supply Voltage-Nom (Vsup):

    1 V

  • Surface Mount:

    YES

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    BOTTOM

  • Width:

    0.87 mm
