NX5P3090UKZ - NXP

Description: NXP - NX5P3090UKZ - USB TYPE-C PD CTRL, AEC-Q100, WLCSP-12

Download NX5P3090UKZ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NX5P3090UKZ - NXP PCB footprint - BGA - BGA - SOT1390-5
click to zoom
3D Models
NX5P3090UKZ - NXP  - 3D model - BGA - SOT1390-5
click to zoom

NX5P3090UKZ Details

  • Manufacturer Part Number:

    NX5P3090UKZ

  • Brand Name:

    NXP Semiconductor

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    WLCSP-12

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.01

  • Factory Lead Time:

    20 Weeks

  • Manufacturer:

    NXP Semiconductors

  • YTEOL:

    5

  • Adjustable Threshold:

    YES

  • Analog IC - Other Type:

    USB PD CONTROLLER

  • JESD-30 Code:

    R-PBGA-B12

  • Length:

    1.65 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    12

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VFBGA

  • Package Shape:

    RECTANGULAR

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.565 mm

  • Supply Voltage-Max (Vsup):

    5.5 V

  • Supply Voltage-Min (Vsup):

    2.5 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin/Silver/Copper/Nickel (Sn/Ag/Cu/Ni)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    1.35 mm

NX5P3090UKZ Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the NX5P3090UKZ is 1.65 V to 5.5 V.
  • To ensure proper power-on, the VCC pin should be ramped up slowly (typically within 1 ms) to the desired operating voltage, and the VCC pin should be decoupled with a 10 nF capacitor to GND.
  • The maximum current rating for the NX5P3090UKZ is 20 mA per pin, with a total device current limit of 100 mA.
  • To ensure ESD protection, handle the device by the body, avoid touching the pins, and use an anti-static wrist strap or mat when handling the device.
  • A good PCB layout for the NX5P3090UKZ should include a solid ground plane, short traces, and decoupling capacitors near the VCC pin to minimize noise and ensure signal integrity.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

NX5P3090UKZ Overview

Use the download button to access the NX5P3090UKZ schematic symbol, PCB footprint, and 3D model.
