NX71C50003 - Diodes Incorporated

Description: 125 MHz XO (Standard) LVCMOS Oscillator 3.3V Enable/Disable 6-SMD, No Lead , 3.3V , -40°C ~ 85°C , 60mA

Download NX71C50003 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
NX71C50003 - Diodes Incorporated PCB footprint - Other - Other - 6-SMD_2025-1.9
click to zoom
3D Models
NX71C50003 - Diodes Incorporated  - 3D model - Other - 6-SMD_2025-1.9
click to zoom

NX71C50003 Details

  • Manufacturer Part Number:

    NX71C50003

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    6

  • Additional Feature:

    STANDBY; ENABLE/DISABLE FUNCTION; TR, 7 INCH

  • Fall Time-Max:

    3 ns

  • Frequency Adjustment-Mechanical:

    NO

  • Frequency Stability:

    25%

  • Mounting Feature:

    SURFACE MOUNT

  • Operating Frequency-Nom:

    125 MHz

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Oscillator Type:

    LVCMOS

  • Output Load:

    15 pF

  • Physical Dimension:

    7.0mm x 5.0mm x 1.4mm

  • Rise Time-Max:

    3 ns

  • Supply Voltage-Max:

    3.465 V

  • Supply Voltage-Min:

    3.135 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    YES

  • Symmetry-Max:

    45/55 %

NX71C50003 Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the NX71C50003 is 2.7V to 5.5V, as specified in the datasheet. However, it's essential to note that the device can tolerate a voltage range of 2.3V to 6.5V for short durations, but prolonged operation outside the recommended range may affect its performance and lifespan.
  • To ensure proper power-on and power-off sequencing, it's recommended to follow the guidelines outlined in the datasheet. Specifically, the VCC pin should be powered on before the VPP pin, and the VPP pin should be powered off before the VCC pin. Additionally, the power supply should be stable and free from noise to prevent unwanted resets or malfunctions.
  • The NX71C50003 supports a maximum clock frequency of 100 MHz, as specified in the datasheet. However, the actual clock frequency may be limited by the system design, PCB layout, and other factors. It's essential to ensure that the clock signal is clean, stable, and within the recommended specifications to maintain reliable operation.
  • The NX71C50003 has a power-down mode that can be activated by pulling the CE pin low. When in power-down mode, the device consumes minimal power and can help reduce overall system power consumption. However, it's essential to ensure that all inputs are held at a valid logic level during power-down mode to prevent unwanted device behavior.
  • The NX71C50003 has a maximum junction temperature (TJ) of 150°C. To ensure reliable operation, it's essential to provide adequate thermal management, such as heat sinks, thermal pads, or other cooling mechanisms, to keep the device temperature within the recommended range. The datasheet provides thermal resistance values to help with thermal design calculations.
