PA89 - Apex Microtechnology

PA89 Details

• Manufacturer Part Number:

  PA89

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  DFM

• Pin Count:

  12

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Apex Microtechnology Inc

• YTEOL:

  4.15

• Amplifier Type:

  OPERATIONAL AMPLIFIER

• Architecture:

  VOLTAGE-FEEDBACK

• Average Bias Current-Max (IIB):

  0.00005 µA

• Bias Current-Max (IIB) @25C:

  0.00005 µA

• Common-mode Reject Ratio-Min:

  96 dB

• Common-mode Reject Ratio-Nom:

  110 dB

• Frequency Compensation:

  NO

• Input Offset Voltage-Max:

  2000 µV

• JESD-30 Code:

  R-MDFM-P12

• Low-Bias:

  YES

• Low-Offset:

  NO

• Micropower:

  NO

• Neg Supply Voltage Limit-Max:

  -600 V

• Neg Supply Voltage-Nom (Vsup):

  -500 V

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  METAL

• Package Code:

  DIP

• Package Equivalence Code:

  DIP12,1.2,200TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Power:

  YES

• Programmable Power:

  NO

• Qualification Status:

  Not Qualified

• Slew Rate-Min:

  12 V/us

• Slew Rate-Nom:

  16 V/us

• Supply Current-Max:

  6 mA

• Supply Voltage Limit-Max:

  600 V

• Supply Voltage-Nom (Vsup):

  500 V

• Surface Mount:

  NO

• Technology:

  MOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  NICKEL

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  5.08 mm

• Terminal Position:

  DUAL

• Unity Gain BW-Nom:

  10000

• Voltage Gain-Min:

  250000

• Wideband:

  NO
