A good PCB layout is crucial for optimal performance. TI recommends a 4-layer PCB with a solid ground plane, and to keep the analog and digital grounds separate. Also, keep the input and output traces short and away from each other to minimize noise and crosstalk.
The choice of gain resistors depends on the desired gain and input impedance. TI provides a gain resistor calculator tool to help with the selection. Additionally, consider the tolerance and temperature coefficient of the resistors to ensure stability and accuracy.
The maximum power dissipation of the PGA2311UA/1K is 1.4W. However, this can be affected by the operating conditions, such as supply voltage, temperature, and output load. Be sure to check the thermal characteristics and follow proper thermal design guidelines to ensure reliable operation.
The PGA2311UA/1K has a built-in low-pass filter, but additional filtering may be necessary depending on the application. Consider adding external filters, such as a ferrite bead or a passive RC filter, to reduce noise and interference. Also, ensure proper grounding and shielding of the PCB to minimize electromagnetic interference.
To ensure proper operation, power up the PGA2311UA/1K in the following sequence: VCC, AVCC, and then DVCC. This sequence helps prevent latch-up and ensures that the internal voltage regulators are properly enabled.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
PGA2311UA/1K Overview
Use the download button to access the PGA2311UA/1K schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PGA23,
or try a keyword search, such as Audio Control ICs
