Mitsubishi Electric recommends a 4-layer PCB with a solid ground plane and thermal vias to dissipate heat. A minimum of 1 oz copper thickness is recommended. Additionally, a thermal pad on the bottom of the package should be connected to a heat sink or a thermal plane on the PCB.
To ensure reliable operation in high-temperature environments, it's essential to follow the recommended derating curves for the device. Additionally, consider using a heat sink or thermal management system to keep the junction temperature below 125°C. It's also crucial to ensure good airflow and avoid thermal hotspots.
The PS21964-4S has built-in ESD protection, but it's still essential to follow proper handling and storage precautions to prevent damage. Use an anti-static wrist strap, mat, or packaging materials, and avoid touching the device's pins or exposed internal components.
Yes, the PS21964-4S is suitable for high-reliability and safety-critical applications. However, it's essential to follow Mitsubishi Electric's guidelines for reliability and safety, and to perform thorough testing and validation to ensure the device meets the specific application requirements.
Mitsubishi Electric recommends following the JEDEC J-STD-020D.1 standard for soldering and rework conditions. The recommended peak temperature is 260°C, with a maximum time above 217°C of 30 seconds. It's also essential to use a soldering iron with a temperature control system to prevent overheating.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
PS21964-4S Overview
Use the download button to access the PS21964-4S schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PS219,
or try a keyword search, such as Motion Control Electronics
