PTLIN10285DRQ1 - Texas Instruments

PTLIN10285DRQ1 Details

• Manufacturer Part Number:

  PTLIN10285DRQ1

• Brand Name:

  Texas Instruments

• Part Life Cycle Code:

  Obsolete

• Package Description:

  SOIC-8

• Date Of Intro:

  2019-09-07

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• JESD-30 Code:

  R-PDSO-G8

• Length:

  4.905 mm

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Screening Level:

  AEC-Q100

• Seated Height-Max:

  1.75 mm

• Supply Voltage-Nom:

  12 V

• Surface Mount:

  YES

• Telecom IC Type:

  INTERFACE CIRCUIT

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  3.895 mm
