PTN5150HX - NXP

PTN5150HX Details

• Manufacturer Part Number:

  PTN5150HX

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  X2QFN-12

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  NXP Semiconductors

• YTEOL:

  3

• Additional Feature:

  ESD Value for CC1, CC2, VBUS_DET pins is 3A

• Adjustable Threshold:

  NO

• Analog IC - Other Type:

  USB PD CONTROLLER

• JESD-30 Code:

  S-PQCC-N12

• Length:

  1.6 mm

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VQCCN

• Package Equivalence Code:

  LCC12,.063SQ,16

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, VERY THIN PROFILE

• Seated Height-Max:

  0.4 mm

• Supply Current-Max (Isup):

  0.13 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Threshold Voltage-Nom:

  +0.2V

• Width:

  1.6 mm
