PTPS7A7833PWPT - Texas Instruments

Description: 120-mA smart AC/DC low-dropout (LDO) linear voltage regulator

Download PTPS7A7833PWPT Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
PTPS7A7833PWPT - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - pwp (r-pdso-g14)-ren1
click to zoom
3D Models
PTPS7A7833PWPT - Texas Instruments  - 3D model - Small Outline Packages - pwp (r-pdso-g14)-ren1
click to zoom

PTPS7A7833PWPT Details

  • Manufacturer Part Number:

    PTPS7A7833PWPT

  • Brand Name:

    Texas Instruments

  • Part Life Cycle Code:

    Active Unconfirmed

  • Package Description:

    HTSSOP-14

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Date Of Intro:

    2019-03-17

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    2

  • Analog IC - Other Type:

    INPUT FAULT PROTECTION CONTROLLER

  • JESD-30 Code:

    R-PDSO-G14

  • Length:

    5 mm

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH

  • Seated Height-Max:

    1.2 mm

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    4.4 mm

PTPS7A7833PWPT Frequently Asked Questions (FAQs)

  • Texas Instruments recommends a 2-layer or 4-layer PCB with a solid ground plane and thermal vias to improve heat dissipation. A minimum of 2 oz copper thickness is recommended for the top and bottom layers.
  • To ensure reliable operation at high temperatures, it's essential to follow the recommended operating conditions, provide adequate heat sinking, and use a thermal interface material (TIM) with a thermal conductivity of at least 1 W/m-K.
  • The maximum allowed voltage on the input pins is 6.5V, which is higher than the recommended operating voltage of 5.5V. However, exceeding the recommended voltage may reduce the device's lifespan.
  • Yes, the PTPS7A7833PWPT is qualified for automotive and high-reliability applications. It meets the AEC-Q100 standard and is designed to operate in harsh environments.
  • Use the equations provided in the datasheet to calculate the power dissipation (PD) and junction temperature (TJ). PD = (VIN - VOUT) x IOUT, and TJ = TA + (PD x θJA), where TA is the ambient temperature and θJA is the junction-to-ambient thermal resistance.
