- Part Number QPQ1904SR
- Manufacturer Qorvo
- Pin Count 12
- Part Category Filter
- Package Category Other
- Footprint Name Other - 3 Pad 1.7x1.1mm Laminate
- Released Date Jan 7, 2025
- Last Modified Date Feb 28, 2025 4:39 PM UTC
- Pinout / Pin List Click Here (Member Only)
QPQ1904SR Details
-
Manufacturer Part Number:
QPQ1904SR
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
HTS Code:
8542.39.00.01
-
Factory Lead Time:
22 Weeks
-
Manufacturer:
Qorvo
-
JESD-609 Code:
e4
-
Moisture Sensitivity Level:
3
-
Peak Reflow Temperature (Cel):
260
-
Telecom IC Type:
TELECOM CIRCUIT
-
Terminal Finish:
Gold (Au) - with Nickel (Ni) barrier
QPQ1904SR Frequently Asked Questions (FAQs)
-
Qorvo provides a recommended PCB layout and land pattern in their application note AN-2171, which can be found on their website. Following this layout and pattern is crucial for achieving optimal performance and minimizing parasitic effects.
-
Qorvo provides a detailed biasing and configuration guide in their application note AN-2172, which covers the recommended voltage and current settings, as well as configuration options for different operating modes.
-
The QPQ1904SR has a maximum junction temperature of 150°C. To ensure proper thermal management, it's essential to follow Qorvo's recommended thermal design guidelines, including using a heat sink, thermal vias, and a thermal interface material. Additionally, the device's thermal resistance and power dissipation should be carefully considered during the design process.
-
The QPQ1904SR has an ESD rating of 2 kV HBM and 100 V MM. To ensure proper ESD protection, it's recommended to follow Qorvo's ESD protection guidelines, including using ESD protection diodes, resistors, and capacitors, as well as implementing proper handling and storage procedures.
-
Qorvo performs a range of reliability and qualification tests on the QPQ1904SR, including temperature cycling, humidity testing, and electrical stress testing. The device is also qualified according to AEC-Q102 and meets the requirements of various industry standards, such as ISO/TS 16949 and IATF 16949.
