R1EV5801MBTDRDI#B0 - Renesas Electronics

R1EV5801MBTDRDI#B0 Details

• Manufacturer Part Number:

  R1EV5801MBTDRDI#B0

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  TSOP(1)

• Package Description:

  TSOP-32

• Pin Count:

  32

• Manufacturer Package Code:

  PTSA0032KD

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Access Time-Max:

  250 ns

• Additional Feature:

  IT ALSO HAVE ACCESS TIME 150 NS OPERATES AT 4.5 TO 5.5 V SUPPLY VOLTAGE

• JESD-30 Code:

  R-PDSO-G32

• Length:

  12.4 mm

• Memory Density:

  1048576 bit

• Memory IC Type:

  EEPROM

• Memory Width:

  8

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  32

• Number of Words:

  131072 words

• Number of Words Code:

  128000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  128KX8

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Parallel/Serial:

  PARALLEL

• Programming Voltage:

  3 V

• Seated Height-Max:

  1.2 mm

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Width:

  8 mm

• Write Cycle Time-Max (tWC):

  10 ms
