RAA270005KFP - Renesas Electronics

RAA270005KFP Details

• Manufacturer Part Number:

  RAA270005KFP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  HLQFP-40

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  7.05

• Adjustable Threshold:

  YES

• Analog IC - Other Type:

  INTEGRATED POWER MANAGEMENT UNIT

• JESD-30 Code:

  S-PQFP-G40

• Length:

  7 mm

• Number of Channels:

  10

• Number of Functions:

  1

• Number of Terminals:

  40

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HLQFP

• Package Equivalence Code:

  QFP40,.35SQ

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, HEAT SINK/SLUG, LOW PROFILE

• Seated Height-Max:

  1.7 mm

• Supply Voltage-Max (Vsup):

  18.5 V

• Supply Voltage-Min (Vsup):

  6.6 V

• Supply Voltage-Nom (Vsup):

  12 V

• Surface Mount:

  YES

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  QUAD

• Width:

  7 mm
