S-8215AAF-K8T2U - SII Semiconductor

Description: Battery Management Li-Ion Secondary Bat Protection 4/5 cells

Download S-8215AAF-K8T2U Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
S-8215AAF-K8T2U - SII Semiconductor PCB footprint - Small Outline Packages - Small Outline Packages - TMSOP8-A-PKG
click to zoom
3D Models
S-8215AAF-K8T2U - SII Semiconductor  - 3D model - Small Outline Packages - TMSOP8-A-PKG
click to zoom

S-8215AAF-K8T2U Details

  • Manufacturer Part Number:

    S-8215AAF-K8T2U

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    MSOP

  • Package Description:

    TMSOP-8

  • Pin Count:

    8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    ABLIC Inc.

  • YTEOL:

    6

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    SECONDARY BATTERY PROTECTOR

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Length:

    2.9 mm

  • Number of Channels:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH

  • Seated Height-Max:

    0.8 mm

  • Supply Voltage-Max (Vsup):

    26 V

  • Supply Voltage-Min (Vsup):

    3.6 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    2.8 mm

S-8215AAF-K8T2U Frequently Asked Questions (FAQs)

  • Although the datasheet specifies an input voltage range of 3.5V to 10V, it's recommended to limit the input voltage to 9V or less to ensure stable operation and prevent overheating.
  • To ensure output voltage stability, it's essential to use a suitable output capacitor with a capacitance value between 1uF and 10uF, and an ESR (Equivalent Series Resistance) of 1Ω or less. Additionally, the input capacitor should have a capacitance value of at least 1uF.
  • The minimum input voltage required for the S-8215AAF-K8T2U to operate is 3.5V. However, the output voltage may not be regulated properly if the input voltage drops below 3.8V.
  • The S-8215AAF-K8T2U is rated for operation up to 105°C. However, the output current may need to be derated at higher temperatures to prevent overheating. It's recommended to consult the datasheet and perform thermal calculations to ensure safe operation.
  • The power dissipation of the S-8215AAF-K8T2U can be calculated using the formula: Pd = (Vin - Vout) x Iout, where Vin is the input voltage, Vout is the output voltage, and Iout is the output current. It's essential to consider the power dissipation to ensure the device operates within its thermal limits.
