SC40-19SRWA - Kingbright

Description: DISPLAY, SEVEN SEGMENT, 100MM, RED; LED Color:Red; Forward Current If:20mA; Forward Voltage:7.4V; Luminous Intensity:105mcd; No. of Digits / Alpha:1; Character Size:101.2mm; Common Connection:Common Cathode; Product Range:- RoHS Compliant: Yes

Download SC40-19SRWA Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SC40-19SRWA - Kingbright - PCB symbol
click to zoom
PCB Footprints
SC40-19SRWA - Kingbright PCB footprint - Dual-In-Line Sockets - Dual-In-Line Sockets - 101.2mm (4.0INCH)SINGLE DIGIT NUMERIC DISPLAY
click to zoom
3D Models
SC40-19SRWA - Kingbright - 3D model - Dual-In-Line Sockets - 101.2mm (4.0INCH)SINGLE DIGIT NUMERIC DISPLAY
click to zoom

SC40-19SRWA Details

  • Manufacturer Part Number:

    SC40-19SRWA

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Transferred

  • Package Description:

    ROHS COMPLIANT PACKAGE-10

  • Country Of Origin:

    Mainland China

  • HTS Code:

    8541.40.20.00

  • Manufacturer:

    Kingbright

  • YTEOL:

    6

  • Additional Feature:

    IC COMPATIBLE

  • Color:

    SUPER BRIGHT RED

  • Color@Wavelength:

    Red

  • Configuration:

    COMMON CATHODE, 1 DIGIT WITH DECIMAL POINT

  • Display Height:

    101.2 mm

  • Forward Current-Max:

    0.03 A

  • Number of Characters:

    1

  • Number of Functions:

    1

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    7 SEG NUMERIC LED DISPLAY

  • Peak Wavelength:

    660 nm

SC40-19SRWA Frequently Asked Questions (FAQs)

  • The recommended storage temperature range for the SC40-19SRWA is -30°C to 30°C, with a relative humidity of 60% or less.
  • Yes, the SC40-19SRWA is suitable for outdoor applications, but it's recommended to use a suitable enclosure or coating to protect it from moisture and UV radiation.
  • The maximum forward current that can be applied to the SC40-19SRWA is 30mA, but it's recommended to operate it at a lower current to ensure a longer lifespan.
  • Yes, the SC40-19SRWA is compatible with lead-free soldering processes, with a peak reflow temperature of 260°C.
  • The typical viewing angle of the SC40-19SRWA is 120°, but this can vary depending on the specific application and optical design.

Trust Checks

This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SC40-19SRWA Overview

Use the download button to access the SC40-19SRWA schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SC40-, or try a keyword search, such as LED Displays
