SIT8008BCL82-33S-24.576000 - SiTime

SIT8008BCL82-33S-24.576000 Details

• Manufacturer Part Number:

  SIT8008BCL82-33S-24.576000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Malaysia, Taiwan, Thailand

• Manufacturer:

  SiTime Corporation

• YTEOL:

  6

• Additional Feature:

  STANDBY; ENABLE/DISABLE FUNCTION; ALSO COMPATIBLE WITH HCMOS O/P

• Fall Time-Max:

  2 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  24.576 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Oscillator Type:

  LVCMOS

• Output Load:

  15 pF

• Output Low Current-Max:

  4 mA

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  DILCC4,.2,200

• Packing Method:

  BULK

• Physical Dimension:

  7mm x 5mm x 0.9mm

• Rise Time-Max:

  2 ns

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)
