SKF620002 - Diodes Incorporated

SKF620002 Details

• Manufacturer Part Number:

  SKF620002

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  6

• Additional Feature:

  STANDBY; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  0.5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  156.25 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCSL

• Output Load:

  50 OHM, 2 pF

• Package Equivalence Code:

  LCC6,.1X.12,65/49

• Packing Method:

  TR, 7 INCH

• Physical Dimension:

  3.2mm x 2.5mm x 0.9mm

• Rise Time-Max:

  0.5 ns

• Screening Level:

  MIL-STD-202; MIL-STD-883

• Supply Current-Max:

  40 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  45/55 %
