SLG47513M - Renesas Electronics

SLG47513M Details

• Manufacturer Part Number:

  SLG47513M

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  MSTQFN

• Package Description:

  MSTQFN-16

• Pin Count:

  16

• Country Of Origin:

  Taiwan

• HTS Code:

  8542.31.00.55

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  6

• In-System Programmable:

  NO

• JESD-30 Code:

  S-XQCC-N16

• JTAG BST:

  NO

• Length:

  1.6 mm

• Moisture Sensitivity Level:

  1

• Number of Dedicated Inputs:

  1

• Number of I/O Lines:

  13

• Number of Inputs:

  14

• Number of Macro Cells:

  23

• Number of Outputs:

  13

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  1 DEDICATED INPUTS, 13 I/O

• Output Function:

  MACROCELL

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Equivalence Code:

  LCC16,.06SQ,16

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Programmable Logic Type:

  OT PLD

• Supply Voltage-Max:

  1.65 V

• Supply Voltage-Min:

  1 V

• Supply Voltage-Nom:

  1.2 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Width:

  1.6 mm
