SLG59H1342CTR - Renesas Electronics

SLG59H1342CTR Details

• Manufacturer Part Number:

  SLG59H1342CTR

• Brand Name:

  Renesas

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  WLCSP-9 (1.21 x 1.21 mm)

• Package Description:

  WLCSP-9

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  7

• Additional Feature:

  THERMAL SHUTDOWN:150C

• Adjustable Threshold:

  YES

• Analog IC - Other Type:

  LOAD SWITCH

• JESD-30 Code:

  R-XBGA-B9

• Length:

  1.21 mm

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  UFBGA

• Package Equivalence Code:

  BGA9,3X3,16

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, ULTRA THIN PROFILE, FINE PITCH

• Seated Height-Max:

  0.625 mm

• Supply Current-Max (Isup):

  0.115 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Threshold Voltage-Nom:

  +2.25V

• Width:

  1.21 mm
