SLG59M1655VTR - Renesas Electronics

SLG59M1655VTR Details

• Manufacturer Part Number:

  SLG59M1655VTR

• Brand Name:

  Renesas

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  STDFN-14 (1.0 x 3.0 mm)

• Package Description:

  STDFN-14

• Pin Count:

  14

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  7

• Additional Feature:

  THERMAL SHUTDOWN:125C

• Adjustable Threshold:

  NO

• Analog IC - Other Type:

  LOAD SWITCH

• JESD-30 Code:

  R-PDSO-N14

• Length:

  3 mm

• Number of Functions:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  USON

• Package Equivalence Code:

  SOLCC14,.04,16

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, ULTRA THIN PROFILE

• Seated Height-Max:

  0.6 mm

• Supply Current-Max (Isup):

  0.1 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  2.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  DUAL

• Width:

  1 mm
