SN74S134N - Texas Instruments

Description: Logic Gates 13-input Positive-NAND gates 16-PDIP 0 to 70

Download SN74S134N Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
SN74S134N - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
SN74S134N - Texas Instruments PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - N (R-PDIP-T)
click to zoom
3D Models
SN74S134N - Texas Instruments - 3D model - Dual-In-Line Packages - N (R-PDIP-T)
click to zoom

SN74S134N Details

  • Manufacturer Part Number:

    SN74S134N

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    No

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    DIP

  • Package Description:

    PLASTIC, MS-001BB, DIP-16

  • Pin Count:

    16

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    0

  • Family:

    S

  • JESD-30 Code:

    R-PDIP-T16

  • Length:

    19.305 mm

  • Load Capacitance (CL):

    15 pF

  • Logic IC Type:

    NAND GATE

  • Number of Functions:

    1

  • Number of Inputs:

    12

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    70 °C

  • Output Characteristics:

    3-STATE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP16,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Power Supply Current-Max (ICC):

    16 mA

  • Propagation Delay (tpd):

    7.5 ns

  • Qualification Status:

    Not Qualified

  • Schmitt Trigger:

    NO

  • Seated Height-Max:

    5.08 mm

  • Supply Voltage-Max (Vsup):

    5.25 V

  • Supply Voltage-Min (Vsup):

    4.75 V

  • Supply Voltage-Nom (Vsup):

    5 V

  • Surface Mount:

    NO

  • Technology:

    TTL

  • Temperature Grade:

    COMMERCIAL

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    7.62 mm

SN74S134N Frequently Asked Questions (FAQs)

  • The maximum clock frequency of the SN74S134N is 100 MHz, but it can vary depending on the operating conditions and the quality of the clock signal.
  • To ensure proper power and decoupling, use a high-quality power supply with a low output impedance, and decouple the VCC pin with a 0.1 μF ceramic capacitor to ground. Additionally, use a 10 μF electrolytic capacitor in parallel to filter out any noise or ripple.
  • The recommended termination scheme for the SN74S134N is to use a series terminator (e.g., 33 Ω) at the far end of the transmission line, and a parallel terminator (e.g., 50 Ω) at the near end. This helps to reduce reflections and ensure signal integrity.
  • The asynchronous reset input (SR) should be tied to VCC through a pull-up resistor (e.g., 1 kΩ) to ensure that the device is properly reset. The SR input should be driven low to reset the device, and then released to allow normal operation.
  • The maximum input voltage that the SN74S134N can tolerate is 5.5 V, which is the absolute maximum rating. However, it's recommended to keep the input voltage within the recommended operating range of 4.5 V to 5.5 V to ensure reliable operation.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

SN74S134N Overview

Use the download button to access the SN74S134N schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SN74S, or try a keyword search, such as Gates

About Texas Instruments

Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
