The maximum cable length depends on the specific application and the type of cable used. However, as a general rule, the SN75160BNE4 can support cable lengths up to 100 meters (328 feet) at a data rate of 1 Mbps. For longer cable lengths or higher data rates, repeaters or other signal conditioning devices may be required.
Yes, the SN75160BNE4 can be used in a multi-point configuration, but it requires additional circuitry to ensure that only one device is transmitting at a time. This can be achieved using a collision detection mechanism or a token-passing protocol.
The SN75160BNE4 has built-in common-mode noise rejection and EMI filtering capabilities. It uses a differential signaling scheme, which helps to reject common-mode noise and improve immunity to EMI. Additionally, the device has a high common-mode rejection ratio (CMRR) of 12 kV/μs, which helps to further reduce the effects of common-mode noise.
The SN75160BNE4 has an operating temperature range of -40°C to 85°C. However, it's recommended to operate the device within a temperature range of 0°C to 70°C for optimal performance and reliability.
Yes, the SN75160BNE4 can be used in a redundant or fault-tolerant system. The device has a built-in fault detection mechanism that can detect faults such as cable breaks or device failures. This allows the system to switch to a redundant channel or device in case of a fault, ensuring continued operation and minimizing downtime.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
SN75160BNE4 Overview
Use the download button to access the SN75160BNE4 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like SN751,
or try a keyword search, such as Line Driver or Receivers
