WITH MASTER SLAVE OPERATION; 3 J & 3 K INPUTS ANDED
Family:
TTL/H/L
JESD-30 Code:
R-CDIP-T14
JESD-609 Code:
e0
Length:
19.56 mm
Load Capacitance (CL):
15 pF
Logic IC Type:
J-K FLIP-FLOP
Max Frequency@Nom-Sup:
15000000 Hz
Max I(ol):
0.016 A
Number of Bits:
2
Number of Functions:
1
Number of Terminals:
14
Operating Temperature-Max:
125 °C
Operating Temperature-Min:
-55 °C
Output Polarity:
COMPLEMENTARY
Package Body Material:
CERAMIC, METAL-SEALED COFIRED
Package Code:
DIP
Package Equivalence Code:
DIP14,.3
Package Shape:
RECTANGULAR
Package Style:
IN-LINE
Packing Method:
TUBE
Power Supply Current-Max (ICC):
20 mA
Prop. Delay@Nom-Sup:
40 ns
Propagation Delay (tpd):
40 ns
Qualification Status:
Not Qualified
Screening Level:
MIL-PRF-38535
Seated Height-Max:
5.08 mm
Supply Voltage-Max (Vsup):
5.5 V
Supply Voltage-Min (Vsup):
4.5 V
Supply Voltage-Nom (Vsup):
5 V
Surface Mount:
NO
Technology:
TTL
Temperature Grade:
MILITARY
Terminal Finish:
Tin/Lead (Sn/Pb)
Terminal Form:
THROUGH-HOLE
Terminal Pitch:
2.54 mm
Terminal Position:
DUAL
Trigger Type:
NEGATIVE EDGE
Width:
7.62 mm
fmax-Min:
15 MHz
SNJ5472J Frequently Asked Questions (FAQs)
Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good layout practices, such as keeping the input and output traces short, using a solid ground plane, and minimizing noise coupling. Additionally, consider using a 4-layer PCB with a dedicated power plane and a separate ground plane.
To ensure stability, follow the recommended compensation network values and layout guidelines. Additionally, ensure that the output capacitor is properly sized and placed close to the output pin. It's also crucial to minimize the loop area and keep the feedback traces short to prevent oscillations.
The SNJ5472J can deliver up to 2A of output current, but this is dependent on the input voltage, output voltage, and thermal conditions. Be sure to check the thermal derating curves and ensure proper heat sinking to prevent overheating.
The SNJ5472J has built-in overvoltage protection (OVP) and undervoltage lockout (UVLO) features. However, it's still recommended to add external protection circuitry, such as a voltage supervisor or a crowbar circuit, to ensure the device is protected from voltage transients and faults.
The recommended input capacitor value is 10uF to 22uF, with a low ESR (Equivalent Series Resistance) and a voltage rating that matches the input voltage. A ceramic or film capacitor is recommended due to their low ESR and high reliability.
