STGIB30M60S-L - STMicroelectronics

Description: SLLIMM - 2nd series IPM, 3-phase inverter, 35 A, 600 V short-circuit rugged IGBT

Download STGIB30M60S-L Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
STGIB30M60S-L - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
STGIB30M60S-L - STMicroelectronics PCB footprint - Other - Other - STGIB30M60S-L
click to zoom
3D Models
STGIB30M60S-L - STMicroelectronics - 3D model - Other - STGIB30M60S-L
click to zoom

STGIB30M60S-L Details

  • Manufacturer Part Number:

    STGIB30M60S-L

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    16 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    5

  • Analog IC - Other Type:

    AC MOTOR CONTROLLER

  • JESD-30 Code:

    R-XZFM-T26

  • Length:

    38 mm

  • Number of Functions:

    1

  • Number of Terminals:

    26

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    ZFM

  • Package Shape:

    RECTANGULAR

  • Package Style:

    MICROELECTRONIC ASSEMBLY

  • Supply Voltage-Max (Vsup):

    18 V

  • Supply Voltage-Min (Vsup):

    13.5 V

  • Supply Voltage-Nom (Vsup):

    15 V

  • Surface Mount:

    NO

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Position:

    ZIG-ZAG

  • Width:

    24 mm

STGIB30M60S-L Frequently Asked Questions (FAQs)

  • The maximum junction temperature (Tj) for the STGIB30M60S-L is 150°C, as specified in the datasheet. However, it's recommended to operate the device at a lower temperature to ensure reliability and longevity.
  • The thermal resistance (Rth) for the STGIB30M60S-L can be calculated using the formula: Rth = (Tj - Ta) / Pd, where Tj is the junction temperature, Ta is the ambient temperature, and Pd is the power dissipation. The datasheet provides the thermal resistance values for different packages and mounting conditions.
  • The recommended gate drive voltage for the STGIB30M60S-L is between 10V and 15V, with a maximum gate-source voltage of ±20V. A higher gate drive voltage can improve switching performance, but it may also increase power losses and EMI.
  • To ensure proper cooling, it's essential to provide a good thermal path from the device to a heat sink or a cooling system. This can be achieved by applying a thermal interface material (TIM) between the device and the heat sink, and ensuring good contact between the two. Additionally, the heat sink should be designed to dissipate the maximum power dissipation of the device.
  • The maximum allowed dv/dt for the STGIB30M60S-L is 50 kV/μs, as specified in the datasheet. Exceeding this value can lead to device failure or malfunction.
