STGIF5CH60TS-X - STMicroelectronics

STGIF5CH60TS-X Details

• Manufacturer Part Number:

  STGIF5CH60TS-X

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  STMicroelectronics

• YTEOL:

  5

• Analog IC - Other Type:

  AC MOTOR CONTROLLER

• JESD-30 Code:

  R-PDFM-T26

• JESD-609 Code:

  e3

• Number of Functions:

  1

• Number of Terminals:

  26

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  16 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Supply Voltage-Max (Vsup):

  16.5 V

• Supply Voltage-Min (Vsup):

  13.5 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  AUTOMOTIVE

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL
