STGIPN3H60AT - STMicroelectronics

STGIPN3H60AT Details

• Manufacturer Part Number:

  STGIPN3H60AT

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-26

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  16 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  5

• Analog IC - Other Type:

  AC MOTOR CONTROLLER

• JESD-30 Code:

  R-XZMA-T26

• Length:

  29.15 mm

• Number of Functions:

  1

• Number of Terminals:

  26

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  ZMA

• Package Equivalence Code:

  MODULE,26LEAD,1.1

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Supply Voltage-Max (Vsup):

  17 V

• Supply Voltage-Min (Vsup):

  12 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  ZIG-ZAG

• Width:

  12.45 mm
