STK554U362C-E - onsemi

STK554U362C-E Details

• Manufacturer Part Number:

  STK554U362C-E

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SIP29 56x21.8

• Package Description:

  SIP-29/21

• Manufacturer Package Code:

  127EZ

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  onsemi

• YTEOL:

  0

• Analog IC - Other Type:

  AC MOTOR CONTROLLER

• JESD-30 Code:

  R-XSMA-T21

• JESD-609 Code:

  e3

• Length:

  62 mm

• Number of Functions:

  1

• Number of Terminals:

  21

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  20 A

• Package Body Material:

  UNSPECIFIED

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP21/29H,.2,1.1FL

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  5.7 mm

• Supply Current-Max (Isup):

  4 mA

• Supply Voltage-Max (Vsup):

  16.5 V

• Supply Voltage-Min (Vsup):

  13.5 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  SINGLE

• Width:

  21.8 mm
