STPA001AH - STMicroelectronics

Description: 4 x 50 W MOSFET quad bridge power amplifier

Download STPA001AH Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
STPA001AH - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
STPA001AH - STMicroelectronics PCB footprint - Other - Other - STPA001AH-6
click to zoom
3D Models
STPA001AH - STMicroelectronics - 3D model - Other - STPA001AH-6
click to zoom

STPA001AH Details

  • Manufacturer Part Number:

    STPA001AH

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    PACKAGE-27

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Factory Lead Time:

    15 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    0

  • Bandwidth-Nom:

    20 kHz

  • Consumer IC Type:

    CLASS AB AUDIO AMPLIFIER

  • Harmonic Distortion:

    0.007%

  • JESD-30 Code:

    R-PZIP-T27

  • JESD-609 Code:

    e3

  • Length:

    29.23 mm

  • Number of Channels:

    4

  • Number of Functions:

    4

  • Number of Terminals:

    27

  • Operating Temperature-Max:

    150 °C

  • Output Power-Nom:

    50 W

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    ZIP

  • Package Equivalence Code:

    ZIP27,.16,.16,40

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Seated Height-Max:

    4.65 mm

  • Supply Voltage-Max (Vsup):

    18 V

  • Supply Voltage-Min (Vsup):

    6 V

  • Surface Mount:

    NO

  • Technology:

    BCD

  • Terminal Finish:

    Bright Tin (Sn) - reflowed

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    1 mm

  • Terminal Position:

    ZIG-ZAG

  • Width:

    15.7 mm
