STPA001H - STMicroelectronics

STPA001H Details

• Manufacturer Part Number:

  STPA001H

• Brand Name:

  STMicroelectronics

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PACKAGE-25

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Factory Lead Time:

  52 Weeks

• Manufacturer:

  STMicroelectronics

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  CLASS AB AUDIO AMPLIFIER

• Harmonic Distortion:

  0.007%

• JESD-30 Code:

  R-PZIP-T25

• Length:

  29.23 mm

• Number of Channels:

  4

• Number of Functions:

  4

• Number of Terminals:

  25

• Operating Temperature-Max:

  150 °C

• Output Power-Nom:

  50 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP27,.16,.16,40

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Seated Height-Max:

  4.65 mm

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  6 V

• Surface Mount:

  NO

• Technology:

  BCD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1 mm

• Terminal Position:

  ZIG-ZAG

• Width:

  15.7 mm
