TA8205AH - Toshiba

TA8205AH Details

• Manufacturer Part Number:

  TA8205AH

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  ZIP

• Package Description:

  HZIP-17

• Pin Count:

  17

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Bandwidth-Nom:

  20 kHz

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  50 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-PSFM-T17

• JESD-609 Code:

  e0

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  17

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Output Power-Nom:

  18 W

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  240

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  250 mA

• Supply Voltage-Max (Vsup):

  18 V

• Supply Voltage-Min (Vsup):

  9 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  OTHER

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED
