TC77 - Cornell Dubilier

TC77 Details

• Manufacturer Part Number:

  TC77

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ,

• Reach Compliance Code:

  Unknown

• ECCN Code:

  EAR99

• HTS Code:

  8532.22.00.40

• Manufacturer:

  Cornell Dubilier Electronics Inc

• YTEOL:

  0

• Capacitance:

  30 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Diameter:

  25.4 mm

• Dielectric Material:

  ALUMINUM (WET)

• ESR:

  5820 mΩ

• JESD-609 Code:

  e0

• Leakage Current:

  0.69713 mA

• Length:

  41.28 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Negative Tolerance:

  10%

• Number of Terminals:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Shape:

  TUBULAR PACKAGE

• Package Style:

  Axial

• Polarity:

  POLARIZED

• Positive Tolerance:

  50%

• Rated (DC) Voltage (URdc):

  450 V

• Ripple Current:

  488 mA

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Shape:

  WIRE
