A good PCB layout for the THS7372IPWR involves keeping the input and output traces as short as possible, using a solid ground plane, and placing the decoupling capacitors close to the device. Additionally, it's recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane.
To optimize the THS7372IPWR for low power consumption, use the lowest possible supply voltage, disable the internal bias when not in use, and use the shutdown pin to turn off the device when not in operation. Additionally, optimizing the output load impedance and using a low-power mode can also help reduce power consumption.
The recommended input impedance for the THS7372IPWR is 50 ohms. This ensures maximum power transfer and optimal performance. However, the device can operate with input impedances ranging from 25 ohms to 100 ohms, but with reduced performance.
Yes, the THS7372IPWR can be used in a differential configuration. In this configuration, the device can provide a differential output with a gain of 2. This configuration is useful in applications where a differential output is required, such as in audio applications.
The maximum operating temperature range for the THS7372IPWR is -40°C to 85°C. However, the device can operate at temperatures above 85°C, but with reduced performance and reliability.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
THS7372IPWR Overview
Use the download button to access the THS7372IPWR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like THS73,
or try a keyword search, such as Audio/Video Amplifiers
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
