TL5580IDR - Texas Instruments

Description: Dual 12MHz, low-noise wide-bandwidth precision amplifier

Download TL5580IDR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TL5580IDR - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - D0008A
click to zoom
3D Models
TL5580IDR - Texas Instruments  - 3D model - Small Outline Packages - D0008A
click to zoom

TL5580IDR Details

  • Manufacturer Part Number:

    TL5580IDR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SOIC

  • Pin Count:

    8

  • Country Of Origin:

    Malaysia, Mexico, Thailand

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Amplifier Type:

    OPERATIONAL AMPLIFIER

  • Architecture:

    VOLTAGE-FEEDBACK

  • Average Bias Current-Max (IIB):

    0.8 µA

  • Bias Current-Max (IIB) @25C:

    0.5 µA

  • Common-mode Reject Ratio-Min:

    110 dB

  • Common-mode Reject Ratio-Nom:

    90 dB

  • Frequency Compensation:

    YES

  • Input Offset Current-Max (IIO):

    0.075 µA

  • Input Offset Voltage-Max:

    1500 µV

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e4

  • Length:

    4.9 mm

  • Low-Bias:

    NO

  • Low-Offset:

    NO

  • Micropower:

    NO

  • Moisture Sensitivity Level:

    1

  • Neg Supply Voltage Limit-Max:

    -18 V

  • Neg Supply Voltage-Nom (Vsup):

    -15 V

  • Number of Functions:

    2

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Packing Method:

    TR

  • Peak Reflow Temperature (Cel):

    260

  • Power:

    NO

  • Programmable Power:

    NO

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.75 mm

  • Slew Rate-Nom:

    5 V/us

  • Subcategory:

    Operational Amplifier

  • Supply Current-Max:

    9 mA

  • Supply Voltage Limit-Max:

    18 V

  • Supply Voltage-Nom (Vsup):

    15 V

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Unity Gain BW-Nom:

    12000

  • Voltage Gain-Min:

    22380

  • Wideband:

    NO

  • Width:

    3.9 mm

TL5580IDR Frequently Asked Questions (FAQs)

  • It is recommended to place the TLV5580IDR close to the ADC input pins, use a ground plane, and keep the analog and digital signals separate. Additionally, use a low-ESR capacitor (e.g., 10nF) between VCC and GND, and a 1kΩ resistor in series with the REF pin to reduce noise.
  • The internal reference voltage can be configured by connecting the REF pin to VCC or GND. For a 2.5V reference, connect REF to VCC. For a 1.25V reference, connect REF to GND through a 1kΩ resistor. Ensure the reference voltage is stable and within the recommended range (1.2V to 2.5V) for optimal performance.
  • The maximum sampling rate for the TLV5580IDR is 200ksps. As the sampling rate increases, the power consumption also increases. To minimize power consumption, use the lowest sampling rate required for your application. However, be aware that lower sampling rates may affect the converter's accuracy and noise performance.
  • The TLV5580IDR's digital output data is in a 10-bit, right-justified, binary format. The data is output on the D[9:0] pins, with D[9] being the most significant bit. Ensure your microcontroller or digital system can handle this data format and sampling rate to accurately process the converted data.
  • The TLV5580IDR has a maximum operating temperature range of -40°C to 125°C. High temperatures can affect the device's accuracy, noise performance, and power consumption. Ensure proper thermal design, including heat sinking and airflow, to maintain a stable operating temperature and optimal performance.
