The recommended power-on sequence is to apply VCC first, followed by AVCC, and then the analog input signals. This ensures proper device operation and prevents latch-up.
Check the analog input signal range, ensure it is within the specified range of 0 to VREF. Also, verify the clock frequency, it should be within the specified range of 1.5 MHz to 4 MHz. If the issue persists, check the digital output format, it should be in two's complement format.
The VREF pin is used to set the reference voltage for the analog-to-digital conversion. It determines the full-scale range of the ADC. Typically, it is connected to a voltage reference source or a resistive divider network to set the desired voltage range.
Yes, the TLC1542IN can be used in a multiplexed mode. The device has a built-in track-and-hold circuit, which allows it to sample multiple analog input channels. However, the multiplexing rate should be limited to ensure that the device has sufficient time to settle and convert the analog signal.
The maximum clock frequency that can be used with the TLC1542IN is 4 MHz. However, it is recommended to operate the device at a clock frequency of 3.5 MHz or less to ensure reliable operation and to minimize the effects of clock jitter.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
TLC1542IN Overview
Use the download button to access the TLC1542IN schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TLC15,
or try a keyword search, such as Analog to Digital Converters
