TLP2362(E(O - Toshiba

Description: TOSHIBA - TLP2362(E(O - OPTOCOUPLER,10MBPS,OPEN COLL,3.3V/5V

Download TLP2362(E(O Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLP2362(E(O - Toshiba PCB footprint - Small Outline Packages - Small Outline Packages - 11-4L1S
click to zoom
3D Models
TLP2362(E(O - Toshiba  - 3D model - Small Outline Packages - 11-4L1S
click to zoom

TLP2362(E(O Details

  • Manufacturer Part Number:

    TLP2362(E(O

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOP-6/5

  • HTS Code:

    8541.40.80.00

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    9

  • Additional Feature:

    OPEN COLLECTOR, UL RECOGNIZED

  • Configuration:

    SINGLE

  • Data Rate-Nom:

    10 MBps

  • Forward Current-Max:

    0.025 A

  • Isolation Voltage-Max:

    3750 V

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Elements:

    1

  • Number of Functions:

    1

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    LOGIC IC OUTPUT OPTOCOUPLER

  • Response Time-Nom:

    1.28e-8 ns

  • Supply Voltage-Min:

    2.7 V

  • Surface Mount:

    YES

TLP2362(E(O Frequently Asked Questions (FAQs)

  • Toshiba recommends a PCB layout with a solid ground plane, short traces, and minimal impedance to ensure high-speed signal integrity and minimize electromagnetic interference (EMI). A 4-layer PCB with a dedicated ground plane is recommended.
  • To ensure reliable operation in high-temperature environments, it is essential to follow proper thermal design and layout guidelines. This includes providing adequate heat sinking, using thermal vias, and keeping the device away from heat sources. Additionally, the device should be operated within its recommended temperature range of -40°C to 125°C.
  • The TLP2362(E) has built-in ESD protection, but it is still recommended to follow proper ESD handling and protection procedures during assembly and testing. This includes using ESD-safe materials, grounding straps, and ionizers to minimize the risk of ESD damage.
  • Yes, the TLP2362(E) is designed to be a low-power device, with a typical quiescent current of 1.5 mA. However, to minimize power consumption, it is recommended to use the device's shutdown mode, which reduces the quiescent current to less than 1 μA.
  • To troubleshoot issues with the TLP2362(E), it is recommended to follow a systematic approach, starting with a review of the device's datasheet and application notes. This should be followed by a thorough inspection of the PCB layout and assembly, as well as verification of the device's operating conditions and signal integrity. If issues persist, it may be necessary to use specialized test equipment, such as an oscilloscope or logic analyzer, to debug the design.
