TLP372(F) - Toshiba

TLP372(F) Details

• Manufacturer Part Number:

  TLP372(F)

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PLASTIC, 11-7A8, DIP-6

• HTS Code:

  8541.40.80.00

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Additional Feature:

  UL RECOGNIZED

• Coll-Emtr Bkdn Voltage-Min:

  300 V

• Configuration:

  SINGLE WITH BUILT-IN DIODE AND RESISTOR

• Current Transfer Ratio-Min:

  1000%

• Current Transfer Ratio-Nom:

  4000%

• Dark Current-Max:

  200 nA

• Forward Current-Max:

  0.025 A

• Forward Voltage-Max:

  1.3 V

• Isolation Voltage-Max:

  5000 V

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Elements:

  1

• On-State Current-Max:

  0.15 A

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Optoelectronic Device Type:

  DARLINGTON OUTPUT OPTOCOUPLER

• Power Dissipation-Max:

  0.35 W

• Response Time-Max:

  0.00004 s

• Surface Mount:

  NO
