TLP5754H(LF4,E - Toshiba

Description: Gate Drive Coupler; 125C oper temp; R2R; SO6L

Download TLP5754H(LF4,E Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLP5754H(LF4,E - Toshiba PCB footprint - Small Outline Packages - Small Outline Packages - SO6L
click to zoom
3D Models
TLP5754H(LF4,E - Toshiba  - 3D model - Small Outline Packages - SO6L
click to zoom

TLP5754H(LF4,E Details

  • Manufacturer Part Number:

    TLP5754H(LF4,E

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOP-6

  • HTS Code:

    8541.40.80.00

  • Factory Lead Time:

    14 Weeks

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    9

  • Additional Feature:

    OPEN COLLECTOR, UL RECOGNIZED

  • Configuration:

    SINGLE

  • Forward Current-Max:

    0.02 A

  • Isolation Voltage-Max:

    5000 V

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Elements:

    1

  • Number of Functions:

    1

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    LOGIC IC OUTPUT OPTOCOUPLER

  • Packing Method:

    MAGAZINE

  • Response Time-Nom:

    1.5e-8 ns

  • Supply Voltage-Min:

    15 V

  • Surface Mount:

    YES

TLP5754H(LF4,E Frequently Asked Questions (FAQs)

  • Toshiba recommends a 4-layer PCB with a solid ground plane and a separate power plane for the input and output stages. The input and output pins should be placed on opposite sides of the PCB to minimize electromagnetic interference (EMI). Additionally, the PCB should have a low impedance path for the output current to ensure stable operation.
  • To ensure reliability in high-temperature applications, it is essential to follow proper thermal design and management practices. This includes providing adequate heat sinking, using a thermally conductive PCB material, and ensuring good airflow around the device. Additionally, the device should be operated within its recommended temperature range, and the junction temperature should be monitored to prevent overheating.
  • The maximum allowable voltage drop across the input and output pins of the TLP5754H is 1.5V. Exceeding this voltage drop can lead to reduced performance, increased power consumption, and potentially even damage to the device.
  • Yes, the TLP5754H can be used in applications with high-frequency switching. However, it is essential to ensure that the device is properly bypassed and decoupled to minimize electromagnetic interference (EMI) and radio-frequency interference (RFI). Additionally, the PCB layout should be designed to minimize parasitic inductance and capacitance.
  • To troubleshoot issues with the TLP5754H, start by verifying the input voltage, output current, and PCB layout. Check for any signs of overheating, and ensure that the device is properly bypassed and decoupled. Use an oscilloscope to monitor the output voltage and current, and look for any signs of oscillation or ringing. If the issue persists, consult the datasheet and application notes for further guidance.
