TMC2660C-PA-T - Analog Devices

Description: -40°C ~ 125°C Bipolar Motor Driver Power MOSFET SPI, Step/Direction 44-PQFP

Download TMC2660C-PA-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TMC2660C-PA-T - Analog Devices PCB footprint - Quad Flat Packages - Quad Flat Packages - 44-LQFP-10X10X1.4
click to zoom
3D Models
TMC2660C-PA-T - Analog Devices  - 3D model - Quad Flat Packages - 44-LQFP-10X10X1.4
click to zoom

TMC2660C-PA-T Details

  • Manufacturer Part Number:

    TMC2660C-PA-T

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    QFP-44

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Analog Devices Inc

  • YTEOL:

    9

  • Analog IC - Other Type:

    STEPPER MOTOR CONTROLLER

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Time@Peak Reflow Temperature-Max (s):

    30

TMC2660C-PA-T Frequently Asked Questions (FAQs)

  • A good PCB layout for optimal thermal performance involves placing the TMC2660C-PA-T near the edge of the board, using a large copper area for heat dissipation, and minimizing the number of layers under the device. Additionally, using thermal vias and a thermal pad can help to dissipate heat more efficiently.
  • The TMC2660C-PA-T can be configured for different motor types and applications using the SPI interface. The device has several registers that can be programmed to set the motor type, current limits, acceleration and deceleration rates, and other parameters. The datasheet provides a detailed description of the registers and their functions.
  • The maximum current rating for the TMC2660C-PA-T is 2.5A per phase. The current limit can be calculated using the formula: I_limit = (V_supply - V_dropout) / R_sense, where V_supply is the supply voltage, V_dropout is the voltage drop across the sense resistor, and R_sense is the sense resistor value.
  • To troubleshoot common issues such as motor stalling or overheating, check the motor current and voltage waveforms using an oscilloscope, and verify that the device is properly configured and calibrated. Also, check the thermal performance of the device and the PCB layout to ensure that heat is being dissipated efficiently.
  • The recommended values for the sense resistors and filter capacitors depend on the specific application and motor type. However, as a general guideline, the sense resistor value should be in the range of 0.1 ohms to 1 ohm, and the filter capacitor value should be in the range of 10nF to 100nF.
