- Datasheet Download Datasheet
- Stock & Prices $ Price & Stock for TMDS181RGZR
- Part Number TMDS181RGZR
- Manufacturer Texas Instruments
- Pin Count 49
- Part Category Integrated Circuit
- Package Category Quad Flat No-Lead
- Footprint Name Quad Flat No-Lead - VQFN_48-
- Released Date Aug 3, 2019
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
TMDS181RGZR Details
-
Manufacturer Part Number:
TMDS181RGZR
-
Brand Name:
Texas Instruments
-
Pbfree Code:
Yes
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Country Of Origin:
Philippines
-
ECCN Code:
EAR99
-
HTS Code:
8542.39.00.90
-
Manufacturer:
Texas Instruments
-
YTEOL:
15
-
Interface IC Type:
RETIMER
TMDS181RGZR Frequently Asked Questions (FAQs)
-
Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good high-speed design practices, such as using a solid ground plane, minimizing trace lengths, and using 50-ohm transmission lines.
-
To ensure signal integrity, use a controlled impedance PCB, minimize vias and stubs, and use a common mode filter or common mode choke to reduce electromagnetic interference (EMI).
-
The maximum cable length supported by the TMDS181RGZR depends on the specific application and the type of cable used. As a general guideline, the maximum cable length is around 10 meters for HDMI 2.0 and 3 meters for HDMI 1.4.
-
The TMDS181RGZR is a flexible device that can be configured for different HDMI versions using the MODE pin. For example, to configure the device for HDMI 2.0, tie the MODE pin to VCC, and for HDMI 1.4, tie it to GND.
-
The power consumption of the TMDS181RGZR depends on the operating frequency and the mode of operation. Typically, the device consumes around 150 mA in HDMI 2.0 mode and 100 mA in HDMI 1.4 mode.
Trust Checks
Community Provided
System Verified
Community Approved
TMDS181RGZR Overview
Use the download button to access the TMDS181RGZR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TMDS1,
or try a keyword search, such as Other Interface ICs
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
