TMP814PWR - Texas Instruments

Description: Sensored single phase brushless-DC gate driver for 12V/24V/48V applications

Download TMP814PWR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
TMP814PWR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
TMP814PWR - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - PW0020A
click to zoom
3D Models
TMP814PWR - Texas Instruments - 3D model - Small Outline Packages - PW0020A
click to zoom

TMP814PWR Details

  • Manufacturer Part Number:

    TMP814PWR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    TSSOP

  • Pin Count:

    20

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    1

  • Analog IC - Other Type:

    1-PHASE BRUSHLESS DC MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDSO-G20

  • JESD-609 Code:

    e4

  • Length:

    6.5 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    20

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    0.05 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Equivalence Code:

    TSSOP20,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.2 mm

  • Supply Current-Max (Isup):

    14 mA

  • Supply Voltage-Max (Vsup):

    16 V

  • Supply Voltage-Min (Vsup):

    6 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4.4 mm

TMP814PWR Frequently Asked Questions (FAQs)

  • The maximum power dissipation of the TMP814PWR is 1.5W. However, it's essential to consider the thermal resistance and ambient temperature to ensure the device operates within the recommended temperature range.
  • To configure the TMP814PWR for remote temperature sensing, connect the DQ (data output) pin to a microcontroller or other digital device. Then, use the TMP814PWR's internal diode or an external diode to sense the remote temperature. The TMP814PWR will convert the temperature data to a digital signal, which can be read by the microcontroller.
  • The TMP814PWR has an accuracy of ±1°C (max) over the operating temperature range of -20°C to 100°C. However, this accuracy can be affected by factors such as thermal resistance, self-heating, and noise.
  • While the TMP814PWR can operate up to 150°C, it's not recommended for high-temperature applications above 125°C due to reduced accuracy and potential device degradation. For high-temperature applications, consider using a more specialized temperature sensor like the TMP116 or TMP117.
  • The TMP814PWR's POR and BOR features ensure the device resets correctly during power-up and brown-out conditions. To handle these features, ensure the power supply is stable and within the recommended voltage range (2.7V to 5.5V). Also, consider adding external circuitry to filter out noise and ensure a clean power-up sequence.
