TMP815PWR - Texas Instruments

Description: Variable-Speed Single-Phase Full-Wave Fan-Motor Pre-Driver

Download TMP815PWR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
TMP815PWR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
TMP815PWR - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - PW0016A
click to zoom
3D Models
TMP815PWR - Texas Instruments - 3D model - Small Outline Packages - PW0016A
click to zoom

TMP815PWR Details

  • Manufacturer Part Number:

    TMP815PWR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    TSSOP

  • Pin Count:

    16

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    1

  • Analog IC - Other Type:

    1-PHASE BRUSHLESS DC MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e4

  • Length:

    5 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    0.02 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Equivalence Code:

    TSSOP16,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.2 mm

  • Supply Current-Max (Isup):

    9.5 mA

  • Supply Voltage-Max (Vsup):

    16 V

  • Supply Voltage-Min (Vsup):

    6 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    4.4 mm

TMP815PWR Frequently Asked Questions (FAQs)

  • The maximum power dissipation of the TMP815PWR is 1.4W at a junction temperature of 150°C. However, it's recommended to keep the power dissipation below 1W to ensure reliable operation.
  • To configure the TMP815PWR for remote temperature sensing, connect the DQ pin to a microcontroller or other digital device, and use the TMP815PWR's built-in 1-Wire protocol to communicate with the device. The TMP815PWR can be configured to report temperature data in Celsius or Fahrenheit.
  • The TMP815PWR has an accuracy of ±1°C from -20°C to 100°C, and ±2°C from -40°C to 150°C. This accuracy is specified for the entire operating temperature range of the device.
  • Yes, the TMP815PWR is designed for high-temperature applications and can operate up to 150°C. However, it's essential to ensure that the device is properly heat-sinked and that the power dissipation is kept within the recommended limits to prevent overheating.
  • The TMP815PWR has a built-in POR and BOR feature that resets the device during power-up or when the supply voltage drops below a certain threshold. To handle these features, ensure that your system design can accommodate the POR and BOR timing requirements, and that your software is designed to handle the reset events.
