TMS320C40GFL60 - Texas Instruments

TMS320C40GFL60 Details

• Manufacturer Part Number:

  TMS320C40GFL60

• Brand Name:

  Texas Instruments

• Part Life Cycle Code:

  Not Recommended

• Part Package Code:

  PGA

• Pin Count:

  325

• ECCN Code:

  3A991.A.2

• HTS Code:

  8542.31.00.35

• Date Of Intro:

  1991-05-01

• Manufacturer:

  Texas Instruments

• YTEOL:

  3.9

• Address Bus Width:

  31

• Barrel Shifter:

  YES

• Bit Size:

  32

• Boundary Scan:

  YES

• Clock Frequency-Max:

  60 MHz

• External Data Bus Width:

  32

• Format:

  FLOATING POINT

• Integrated Cache:

  NO

• Internal Bus Architecture:

  MULTIPLE

• JESD-30 Code:

  S-CPGA-P325

• JESD-609 Code:

  e4

• Length:

  47.245 mm

• Low Power Mode:

  YES

• Number of DMA Channels:

  6

• Number of External Interrupts:

  5

• Number of Terminals:

  325

• Number of Timers:

  2

• On Chip Data RAM Width:

  8

• On Chip Program ROM Width:

  8

• Operating Temperature-Max:

  85 °C

• Package Body Material:

  CERAMIC, METAL-SEALED COFIRED

• Package Code:

  IPGA

• Package Equivalence Code:

  SPGA325,35X35MOD

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, INTERSTITIAL PITCH

• Qualification Status:

  Not Qualified

• RAM (words):

  8192

• ROM Programmability:

  MROM

• Seated Height-Max:

  5.08 mm

• Supply Current-Max:

  950 mA

• Supply Voltage-Max:

  5.25 V

• Supply Voltage-Min:

  4.75 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Finish:

  Gold (Au)

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  PERPENDICULAR

• Width:

  47.245 mm

• uPs/uCs/Peripheral ICs Type:

  DIGITAL SIGNAL PROCESSOR, OTHER
