TMS4C1024-80N - Texas Instruments

TMS4C1024-80N Details

• Manufacturer Part Number:

  TMS4C1024-80N

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DIP-18

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.02

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Access Mode:

  FAST PAGE

• Access Time-Max:

  80 ns

• Additional Feature:

  RAS ONLY/CAS BEFORE RAS/HIDDEN REFRESH

• I/O Type:

  SEPARATE

• JESD-30 Code:

  R-PDIP-T18

• Length:

  22.48 mm

• Memory Density:

  1048576 bit

• Memory IC Type:

  FAST PAGE DRAM

• Memory Width:

  1

• Number of Functions:

  1

• Number of Ports:

  1

• Number of Terminals:

  18

• Number of Words:

  1048576 words

• Number of Words Code:

  1000000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  1MX1

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP18,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Refresh Cycles:

  512

• Seated Height-Max:

  5.08 mm

• Standby Current-Max:

  0.002 A

• Supply Current-Max:

  0.075 mA

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  4.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  7.62 mm
