Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good PCB design practices, such as keeping the input and output capacitors close to the IC, using a solid ground plane, and minimizing trace lengths and widths to reduce EMI and noise.
The choice of input and output capacitors depends on the specific application requirements. Generally, use low-ESR capacitors with a high ripple current rating. For the input capacitor, a 10uF to 22uF ceramic capacitor is recommended, while for the output capacitor, a 22uF to 47uF ceramic capacitor is suitable. Consult the datasheet and application notes for more guidance.
The TPS16411DRCR is rated for operation up to 85°C ambient temperature. However, it's essential to consider the junction temperature (TJ) and ensure it stays within the recommended range (–40°C to 150°C) to maintain reliability and prevent thermal shutdown.
The TPS16411DRCR has built-in OVP and UVP features. For OVP, the device will shut down if the input voltage exceeds 6.5V. For UVP, the device will shut down if the input voltage falls below 2.5V. Ensure that your design accounts for these voltage limits and provides adequate protection against voltage transients and faults.
The recommended input voltage range for the TPS16411DRCR is 3.5V to 5.5V. Operating outside this range may affect performance, efficiency, and reliability. Consult the datasheet for more information on input voltage tolerance and limitations.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS16411DRCR Overview
Use the download button to access the TPS16411DRCR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS16,
or try a keyword search, such as Power Management Circuits
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
