The maximum input voltage that can be applied to the TPS2003CDRCR is 12V, but it's recommended to operate within the recommended operating conditions of 2.7V to 5.5V for optimal performance and reliability.
To ensure proper power-on and power-off, it's recommended to follow a soft-start sequence, where the input voltage is ramped up slowly (typically 1-10 ms) to prevent inrush currents and voltage spikes.
For optimal performance, it's recommended to follow a compact layout with minimal trace lengths, and place the TPS2003CDRCR close to the power source and load. Additionally, ensure that the input and output capacitors are placed as close as possible to the device.
To handle thermal considerations, ensure that the device is mounted on a PCB with a sufficient thermal mass, and that the thermal pad is connected to a solid ground plane. Additionally, consider using thermal vias and thermal interfaces to improve heat dissipation.
To minimize EMI and EMC issues, ensure that the TPS2003CDRCR is placed in a shielded area, and that the input and output traces are routed away from sensitive analog signals. Additionally, consider using EMI filters and shielding on the PCB to reduce radiated emissions.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS2003CDRCR Overview
Use the download button to access the TPS2003CDRCR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS20,
or try a keyword search, such as Power Management Circuits
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
